Triangle Support Mounting Frame - 4 Solar Panels

Adjustable Triangle Support Solar Mounting Kit for four solar panels.

The overall length of the mounting frame when constructed is 5250mm in length, the rail can be cut down if required. This kit is for solar panels with a depth of 30mm, if you have a different depth panel please let us know and if we can we will swap out the Inter and End Clamps at no extra cost.  We stock 30, 35, 40, 46 and 50mm Inter and End Clamps.

Example - fitting 4 x PEIMAR 400W Solar Modules - OR10H400M

• Width of module: 1134mm x 4 = 4536mm
• Gap between modules: 3 x 17mm = 51mm
• End clamps allowance: 64mm

Total - 4536 + 51+ 64 = 4651mm required.

With the length of the rail in this kit being 5250mm using the panels in this example you would end up with around 599mm excess rail which could be removed if required.

If you need any technical help or have a specific requirement please call our friendly experts for advice.

PRODUCT CODE: KITXGS101-4
