Victron Multiplus-CL 48V 20KW Inverter/Charger
PMC483200400 - The Victron MultiPlus-CL 48V 20kW Inverter/Charger is a powerful and versatile solution for advanced off-grid, backup power and energy storage systems. Combining a high-capacity inverter, battery charger and mains transfer switch into a single unit, it provides comprehensive control over your electrical power system while reducing the need for multiple separate components. With 20kW of inverter power and a maximum charging current of 210A, the MultiPlus-CL is designed for applications where substantial power output and efficient battery charging are required. It can be used with a variety of battery technologies, including lead-acid, AGM and lithium batteries, providing flexibility when designing or upgrading an energy storage system.
The Victron Energy MultiPlus 48/20k/250-100 230V inverter offers advanced functionality and high performance, making it an ideal solution for a range of energy management applications. Its robust design ensures reliable operation in various environments while providing exceptional efficiency. Mains charger, inverter and mains transfer switch in one
- Versatile battery compatibility: Allows connection to various battery types, including lead-acid, AGM and lithium batteries.
- Parallel / Cluster Feature: Units can be paralleled on single phase or more units on 3 phase to make unlimited power using the new Microgrid Cluster feature (Out Soon).
- Power Assist: Prevents overloading of limited AC power sources such as generators or shore power connections by automatically adjusting the battery charging process.
- ESS energy storage solution: Enables the retrofitting of an existing PV system with an energy storage system and uses the Victron Energy Meter to record the power flows.
- Phase compensation: The MultiPlus can also be used in 2-phase or three-phase systems.
- UPS function: Provides an uninterruptible power supply (UPS) for critical loads by automatically switching to inverter operation in the event of a power outage or within 20 milliseconds.
- Combined functions: Combines the features of a charger, inverter and mains transfer switch in one device, including PowerControl and PowerAssist for advanced power management options.
- Versatile topologies: Supports various system configurations, whether in series or parallel to the grid, with or without PV inverters, to cover a wide range of applications.
- Compatibility with additional devices: Can be connected to Victron GX controllers for centralized control or control via the Internet.
- Scalability: Thanks to the possibility of parallel connection and expansion with other Victron devices, the system can be adapted to growing energy needs.
20KW Inverter Power
210A Maximum Charge Current
Combine 3 Units for 3 Phase
VE.Bus Communication
PRODUCT CODE: PMC483200400
